Product description
Pneumatic two-head vertical riveting machine
DF-A-7 Spec.Φ2-Φ6
Two-head vertical riveting and adjustable distance between the two-head is from 35mm to 150mm.
The riveting speed has been doubled than the original one.
It is of the reasonable double-head design,simple and convenient adjustment.
| Model | Spindle travel (mm) | Dia of rivet (mm) |
Distance between punch and table(mm) |
Throat depth (mm) | Motor (kw) | Gauge pressure (kgf/cm2) | Max.output (kgf) | Table size (mm) | NW (kg) | Dimension(mm) |
| DF-A-7 | 0-30 |
solid 2-6 hollow1-9 |
100 | 120 | 0.37 | 2-7 | 750 | 220*320 | 140 | 460*400*1120 |
