Product description
Pneumatic riveting machine
DF-A-5 Spec.Φ2-Φ8
Riveting height is convenient to change.
Movable body of the machine brings convenience for riveting special spare parts.
Take away the working table can rivet the parts with height requirement.
| Model | Spindle travel (mm) | Dia of rivet (mm) |
Distance between punch and table(mm) |
Throat depth (mm) | Motor (kw) | Gauge pressure (kgf/cm2) | Max.output (kgf) | Table size (mm) | NW (kg) | Dimension(mm) |
| DF-A-5 | 0-40 |
solid2-8 hollow1-14 |
125 | 125 | 0.37 | 2-8 | 720 | 180*310 | 95 | 500*370*1100 |
