Product description
Hydraulic horizontal double head riveting machine
DF-C-1 Spec.Φ2-Φ10
Hydraulic horizontal double head riveting machine can rivet spare parts at the same time to improve work efficiency.
The distance between two head is adjustable and easy to rivet spare parts in different sizes.
The speed of riveting machine head is adjustable and automatic riveting tooling is available.
| Model |
Spindle travel (mm) |
Dia of rivet (mm) |
Distance betwe en punch and table(mm) |
Max. Distance between punches (mm) |
Motor (kw) |
Gauge pressure (kgf/cm2) |
Max.output (kgf) |
NW (kg) |
Dimension (mm) |
| DF-C-1 | 0-30 |
solid2-10 hollow2-14 |
190 | 225 | 2.2 | 5-25 | 1450 | 370 | 1800*600*900 |
